• Intel® Xeon® processor E5-4600 product family

  Processor sockets:
  4

  Internal interconnect:
  2 x Intel QuickPath Interconnect (QPI) links; 6.4 GT/s; 7.2 GT/s; 8.0 GT/s

  Cache:
  2.5MB per core; core options: 4, 6, 8

  Form factor:
  2U rack



• Microsoft® Windows Server® 2012
  Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V®)
  Novell® SUSE® Linux Enterprise Server
  Red Hat® Enterprise Linux®
  Virtualization options:
  Citrix® XenServer®
  VMware® vSphere® ESXi ™
  Red Hat Enterprise Virtualization®

• Intel C602

• Up to 3TB (48 DIMM slots) 4GB/8GB/16GB/32GB/64GB DDR3 up to 1866MT/s

• Maximum internal storage
  16TB

• Up to sixteen 2.5” hot-plug SAS, SATA, or SSD

  Hard drives:
  Hot-plug hard drive options:
  2.5” PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K), SAS 512e (15K)
  Self-Encrypting drives available

• 7 PCIe slots:
  Two x16 half-length, full-height
  One x8 half-length, full-height
  Three x8 half-length, half-height
  One x8 half-length, full-height for the RAID controller

• Internal controllers:
  PERC H310
  PERC H710
  PERC H710P
  External HBAs (RAID):
  PERC H810
  External HBAs (non-RAID):
  6Gbps SAS HBA

• Broadcom® 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload)
  Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload)
  Intel X540 dual-port 10GbE Base-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports)
  Broadcom 57800S dual-port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
  Broadcom 57800S dual-port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
  Broadcom 57840S quad-port 10GbE SFP+ Rack NDC (NPAR1.0, SRIOV, DCB, iSCSI and FCoE offloads and CEM)

• Titanium efficiency, hot-plug redundant 750W power supply
  Platinum efficiency, hot-plug redundant 750W or 1100W power supplies
  Auto-ranging power supplies

• High-efficiency, hot-plug, redundant power supplies; hot-plug drive bays; TPM; dual internal SD support; hot-plug
  redundant fans; optional bezel; luggage-tag; ECC memory, interactive LCD screen; extended thermal support;
  ENERGY STAR® compliant, extended power range; Switch Agnostic Partitioning (SWAP)

• Remote management:
  iDRAC7 Express (default) or iDRAC7 Enterprise (upgrade option), both with Lifecycle Controller
  8GB or 16GB vFlash media (upgrade options)

  Systems management:
  IPMI 2.0 compliant
  Dell OpenManage™ Essentials
  Dell OpenManage Power Center
  Dell OpenManage Connections:
  • Dell OpenManage Integration Suite for Microsoft® System Center
  • Dell plug-in for VMware® vCenter™
  • HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management

• ReadyRails II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
  ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks.
