• Intel® Xeon® E5 2600 v3 processors

• Microsoft® Windows Server® 2008 R2
  Microsoft Windows Server 2012
  Microsoft Windows Server 2012 R2
  Novell® SUSE® Linux Enterprise Server
  Red Hat® Enterprise Linux
  VMware® ESX®

• Intel C610 series chipset

• 24 DIMM slots, DDR4 memory
  Architecture: Up to 2133MHz MHz DDR4 DIMMs
  Memory Type: RDIMM&LRDIMM
  Memory Module Sockets: Twenty Four
  Minimum RAM: 2 GB (one module)
  Maximum RAM: Up to 768GB (24 DIMM slots): 4GB/8GB/16GB/32GB DDR4 up to 2133MT/s

• Supported optional hypervisors:
  Microsoft® Windows Server® 2008, with Hyper-V®
  VMware® vSphere® ESXiTM
  Citrix® XenServer®

• SAS, SATA, nearline SAS, SSD, PCIe SSD:
  Up to 68.5TB with 18 x 1.8” 960GB SATA SSD + 8 x 3.5” 1.8TB SAS HDD
  Up to 47.5TB with 24 x 2.5” 1.8TB hot-plug SAS HDD + 2 x 2.5” 1.8TB hot-plug SAS HDD
  Up to 99.6TB with 12 x 3.5 6TB NL SAS HDD or SSD +4 x 3.5 6TB SAS + 2 x 2.5 1.8TB SAS HDD or SSD

• Internal hard drive bay and hot-plug backplane:
  Up to 18 x 1.8” SSD: SATA
  Up to 24 x 2.5” + 2 x 2.5” HDD: SAS, SATA, Near-line SAS SSD: SAS, SATA, up to 4 NVMe Express Flash PCIe
  Up to 16 x 3.5” + 2 x 2.5” HDD: SAS, SATA, Near-line SAS SSD: SAS, SATA

• Slot 1: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket
  Slot 2: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket
  Slot 3: Half Length, Half Height, PCIe Gen3 x8 (x16 connector) low profile bracket
  Slot 4: Full Length, Full Height, PCIe Gen3 x16 (x16 connector)
  Slot 5: Full Length, Full Height, PCIe Gen3 x8 (x16 connector)
  Slot 6: Full Length, Full Height, PCIe Gen3 x16 (x16 connector)
  Dedicated RAID card

• Internal:
  PERC H330
  PERC H730
  PERC H730P
  External:
  PERC H830

• 4 x 1Gb, 2 x 10Gb

• Broadcom® 5719 quad-port 1Gb NIC
  Broadcom 5720 dual-port 1Gb NIC
  Broadcom 57810 dual-port 10Gb DA/SFP+ CNA
  Broadcom 57810 dual-port 10Gb Base-T network adapter
  Intel® Ethernet I350 dual-port 1Gb server adapter
  Intel Ethernet I350 quad-port 1Gb server adapter
  Intel Ethernet X540 dual-port 10GBASE-T server adapter
  Mellanox® ConnectX®-3 dual-port 10Gb Direct Attach/SFP+ server network adapter
  Mellanox ConnectX-3 dual-port 40Gb Direct Attach/QSFP server network adapter
  Emulex® LPE 12000, single-port 8Gb Fibre Channel HBA
  Emulex LPE 12002, dual-port 8Gb Fibre Channel HBA
  Emulex LPe16000B, single-port 16Gb Fibre Channel HBA
  Emulex LPe16002B, dual-port 16Gb Fibre Channel HBA
  Emulex OneConnect OCe14102-U1-D 2-port PCIe 10GbE CNA
  QLogic® 2560, single-port 8Gb Optical Fibre Channel HBA
  QLogic 2562, dual-port 8Gb Optical Fibre Channel HBA
  Qlogic 2660, single-port 16GB, Fibre Channel HBA, full height
  Qlogic 2662, dual-port 16GB, Fibre Channel HBA, full height

• 1100W AC, 86 mm 13G (Platinum+)
  1100W DC, 86 mm 12G (Gold)
  750W AC, 86 mm 12G (Platinum)
  750W AC, 86 mm 12G (Diamond)
  495W AC, 86 mm 12G (Platinum)

• ECC memory
  Hot-plug hard drives
  Hot-plug redundant cooling
  Hot-plug redundant power
  iDRAC8
  Internal Dual SD Module
  Single Device Data Correction (SDDC)
  Spare Rank
  Support for high availability clustering and virtualization
  Proactive systems management alerts
  iDRAC8 with Lifecycle Controller

• H: 8.73 cm (3.44 in.) x W: 44.40 cm (17.49 in.) x D: 68.40 cm (26.92 in.)

• Dell OpenManage portfolio of systems management solutions, including:
  OpenManage Essentials console
  iDRAC8 with Lifecycle Controller.
