• Microsoft® Windows Server® 2008 R2
  Microsoft Windows Server 2012
  Microsoft Windows Server 2012 R2
  Novell® SUSE® Linux Enterprise Server
  Red Hat® Enterprise Linux
  VMware® ESX®

• Intel C610 series chipset

• Up to 1.5TB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s

• Microsoft® Windows Server® 2008, with Hyper-V®
  VMware® ESXi
  Citrix XenServer

• SAS, SATA, Near-line SAS, SSD, PCIe SSD
  Up to 4 optional Express Flash PCIe SSDs
  Up to 144TB via 18 x 8TB 3.5” HDDs

• Internal hard drive bay and hot-plug backplane:
  Up to 8 x 3.5” SAS, SATA, Near-Line SAS, SSD, PCIe SSD drives with optional flex bay
  Up to 18 x 3.5” SAS, SATA, Near-Line SAS, SSD drives without optional flex bay
  Up to 16 x 2.5” SAS, SATA, Near-line SAS, SSD, PCIe SSD drives with optional flex bay
  Up to 32 x 2.5” SAS, SATA, Near-Line SAS, SSD drives with optional flex bay

• Slot 1: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector)
  Slot 2: Full Length, Full Height, PCH - PCIe Gen2 x4 (x8 connector)
  Slot 3: Full Length, Full Height, CPU1 - PCIe Gen3 x16 (x16 connector)
  Slot 4: Half Length, Full Height, CPU2 - PCIe Gen3 x8 (x8 connector)
  Slot 5: Full Length, Full Height, CPU2 - PCIe Gen2 (DMI) x4 (x8 connector)
  Slot 6: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector)
  Slot 7: Full Length, Full Height, CPU2 - PCIe Gen3 x16 (x16 connector)
  Slot 8: Half Length, Full Height, CPU1 - PCIe Gen3 x8 (x8 connector)

• Internal:
  PERC S130
  PERC H330
  PERC H730
  PERC H730P
  External:
  PERC H830

• 2 x 1Gb

• Broadcom® 5719 quad-port 1Gb NIC
  Broadcom 5720 dual-port 1Gb NIC
  Broadcom 57810 dual-port 10Gb DA/SFP+ CNA
  Broadcom 57810 dual-port 10Gb Base-T network adapter
  Intel® Ethernet I350 dual-port 1Gb server adapter
  Intel Ethernet I350 quad-port 1Gb server adapter
  Intel Ethernet X540 dual-port 10GBASE-T server adapter
  Mellanox® ConnectX®-3 dual-port 10Gb Direct Attach/SFP+ server network adapter
  Mellanox ConnectX-3 dual-port 40Gb Direct Attach/QSFP server network adapter
  Emulex® LPE 12000, single-port 8Gb Fibre Channel HBA
  Emulex LPE 12002, dual-port 8Gb Fibre Channel HBA
  Emulex LPe16000B, single-port 16Gb Fibre Channel HBA
  Emulex LPe16002B, dual-port 16Gb Fibre Channel HBA
  Emulex OneConnect OCe14102-U1-D 2-port PCIe 10GbE CNA
  QLogic® 2560, single-port 8Gb Optical Fibre Channel HBA
  QLogic 2562, dual-port 8Gb Optical Fibre Channel HBA
  Qlogic 2660, single-port 16GB, Fibre Channel HBA, full height
  Qlogic 2662, dual-port 16GB, Fibre Channel HBA, full height

• Titanium efficiency 750W AC power supply
  Gold efficiency 1100W DC power supply
  Platinum efficiency 495W, 750W, 1100W or 1600W AC power supply

• ECC memory
  Hot-plug hard drives
  Hot-plug redundant cooling
  Hot-plug redundant power
  iDRAC8
  Internal Dual SD Module
  Single Device Data Correction (SDDC)
  Spare Rank
  Tool-less chassis
  Support for high availability clustering and virtualization
  Proactive systems management alerts
  iDRAC8 with Lifecycle Controller

• Video Type :Integrated Integrated Matrox G200 with iDRAC8
  Video Memory: 16 MB shared with iDRAC8 application memory

  GPUs – Support for up to four optional 300W internal GPU processing accelerators

• Form Factor: 5U
  Height 443.5 mm (17.5 inch) with feet
             434.5 mm (17.1 inch) without feet
  Width:48.2cm (18.98”)
  Depth:75.09cm (29.56”)
  Max Weight:
  T630 full system with 2.5” HDD:
  Max 2.5"x16 (6 fans) 37.57Kg/82.75lb
  Max 2.5"x32 (6 fans) 40.55Kg/89.32lb
  T630 full system with 3.5” HDD:
  Max 3.5"x18 (6 fans) 49.65 Kg/109.36 lb

• Dell OpenManage portfolio of systems management solutions, including:
  OpenManage Essentials console
  iDRAC8 with Lifecycle Controller
